Flex ATX PSU is a small form factor power supply that is mostly used in slim SFF PCs, mini-ITX cases, HTPC cases and 1U rack-mount server chassis. It is a low-profile PSU having slim design, but is a bit longer than other small form factor PSUs, including SFX and SFX-L power supplies. However, it is shorter than TFX power supplies that are 175mm long. Well, in general, we can also say that a Flex ATX PSU is more of a slimmer or compact form of a TFX PSU.

flex-atx-psu-dimensions

A standard Flex ATX PSU has dimensions as 150mm (L) × 81.5 mm (W) × 40.5mm (H), which is shown in the image above. Most of them come with 40mm fan for cooling, but there are some fanless models available too. The placement of fan can be at the rear or at the front, depending on the manufacturer and the model. These power supplies can often be very loud too because the smaller 40mm fan has higher RPM , and it tends to generate more noise due to it. However, if you find your Flex ATX PSU very loud, then you can replace it better 40mm fans from top brands that are very quiet and delivers great performance.

Flex ATX PSUs are also used in many of the slim SFF desktops and workstations from HP, Dell, IBM, SuperMicro etc. These power supplies generally don’t come in higher wattage capacities, and are mainly used in basic SFF workstation PC, All-in-One PC, HTPC, 1U server cases and in industrial applications. However, you can find some higher wattage Flex ATX PSUs, especially in 500W capacity. Unlike ATX and other SFF power supplies, there are not many options available for FLEX ATX power supplies, because of their relatively limited usage in mainstream world. So, to help you out, here I am going to list down the best available Flex ATX PSUs that you can get for your slim SFF Desktop / Case, or for 1U Server chassis. You can also use them as a Replacement PSU in  your Slim Desktops that originally came with inferior or low capacity Flex ATX PSU or they have been damaged.

Note: Some higher capacity Flex ATX power supplies can have length much greater than 150mm i.e. up to 220mm. These long Flex ATX PSUs are generally used in high-end 1U servers that require more power.

Best Flex ATX Power Supply [up to 400W]

Here are some of the best FLEX ATX PSUs that you can get for your mini-ITX build, slim SFF PC, HTPC or 1U ITX server. All the below mentioned Flex ATX power supplies have dimensions as 150mm (L) × 81.5 mm (W) × 40.5mm (H).

SilverStone SST-FX350-G Flex ATX PSU

Silverstone is a computer hardware brand that is pretty well known for its SFF cases and SFF power supplies (SFX, SFX-L, TFX form factors). It also manufactures CPU Coolers, PC Fans and other computer accessories. Here we have from it a very good Flex ATX power supply, which is SilverStone SST-FX350-G. This is a 350W power supply with 80 Plus Gold certification, and comes with a single 12V Rail that has 27A current on it. The PSU comes with all the required connectors, including a 6-pin PCIe connector that can be used to power a budget mid-range graphics card.

SilverStone-SST-FX350-G-Flex-ATX-PSU

For cooling, it has got a 40mm fan that works well but it is a bit on the louder side of the spectrum. The power supply comes in all black color, which also helps a little bit in better heat dissipation. It comes with safety and protection features such as Over Power Protection (OPP), Over Voltage Protection (OVP), Short Circuit Protection (SCP), and it also has Active PFC of >0.9 at full load for higher efficiency in delivering clean power. The power supply has got braided/sleeved cables, so as to protect it from any kind of damage, due to cut or abrasion. An On/Off switch is also present at the rear for cutting off power in some situations. It is compatible with ATX12V v2.4 specifications, which is the latest ATX12V standard. This power supply can be used in your low profile or slim SFF PC case, 1U rack-mount servers or as a replacement PSU for your pre-built SFF PC. Overall, it is a very good Flex ATX PSU that comes with features that no other Flex STX PSUs offer right now. Recommended by me.

SilverStone SST-FX350-G Flex ATX PSU Specifications
Wattage 350W
12V Rail 29.17A, Single
Fan Size 40mm
80 Plus Certification Gold
PCI-E Connector 6-Pin x 1
Warranty 3 years

Buy SilverStone SST-FX350-G Flex ATX PSU

Seasonic SSP-300SUG Flex ATX PSU

Seasonis is well known for its high-quality industrial and consumer power supplies, and here we have from it Seasonic SSP-300SUG Flex ATX PSU, which is a 300W industrial grade Flex ATX power supply for user in 1U servers and slim small form factor computer builds. This is modular Flex ATX power supply, but in reality, it does not make much of a sense as all the connectors are shared with the 24-pin motherboard connector, and only this is the one, which is removable. Well, this can be clearly understood from the fact that these SFF power supplies don’t have enough space for accommodating modular connecters separately.

Seasonic-SSP-300SUG-Flex-ATX-PSU

This Flex ATX Power Supply is 80 Plus Gold certified for better power efficiency, and comes with a single 12V Rail with 25A current on it, which I think is enough for basic or standard use. It does not come with PCIe connector, but has got SATA connectors, a molex connector, 12V CPU connector and 24-pin & 20-pin ATX connectors for motherboard. There is a 40mm fan (with double ball bearing) at the rear for cooling that works as an exhaust fan, and takes away the heat that is generated inside the power supply. It comes with all the safety and protection features, such as Short circuit protection, Over voltage protection, Over power protection, 100 % Burn-in, high temperature cycled on/off, 100 % HiPot test. Also, it features Active PFC (Power Factor Correction) and DC to DC converter design. Overall, a reliable 300W Flex ATX PSU for normal workloads, servers and for use in smaller builds.

Seasonic SSP-300SUG Flex ATX PSU Specifications
Wattage 300W
12V Rail 25A, Single
Fan Size 40mm
80 Plus Certification Gold
PCI-E Connector NA
Warranty Check with seller

Buy Seasonic SSP-300SUG Flex ATX PSU

FSP Flex ATX 400W PSU

FSP is the company that originally come with Flex ATX Power Supply design, and later on it was included in the standard form factors. Here we have FSP400-60FGGBA which is a 400W Flex ATX Power Supply, with 80 Plus Gold certification. It comes with all necessary connectors including 8-pin (6+2) PCIe connector for supporting a mid-range graphics card at best. The PSU has got dual 12V Rails with total of 36A (18A + 18A) current on it. A 40mm is there at the front of the PSU for cooling down its internal components. The construction quality is good but nothing to boast about.

FSP-Flex-ATX-400W-PSU

The power supply features 100% burn-in test, 100% Hi-pot test, Low Ripple & Noise and comes with all standard safety and protection features. This power supply finds it application in standard, advanced server, NAS, SFF PC and industrial power system. The exact model number of this power supply is FSP400-60FGGBA and it is also available in 500W, 300W, 270W and 250W capacities.

FSP Flex ATX 400W PSU Specifications
Wattage 400W
12V Rail 36A (18A + 18A), Dual
Fan Size 40mm
80 Plus Certification Gold
PCI-E Connector 8-pin (6+2) x 1
Warranty 3 year*

Buy FSP Flex ATX 400W PSU

Athena Power FlexATX 300W PSU

A 300W Flex ATX PSU from Athena Power having 80 Plus Bronze certification. It comes with dual 12V Rails having total combined current of 28A (14A + 14A) on it. A 40mm fan is present at the rear, that works as an exhaust fan for taking out the heat from the components. The power supply comes with all the required connectors, including a 6-pin PCIe connector, which is good enough for powering a budget mid-range graphics card.

Athena-Power-FlexATX-300W-PSU

You can use this PSU in 1U Mini-ITX IPC Rackmount Chassis, IBM SurePOS, Shuttle XPC, various types of Kiosks, HP Pavillion Systems and other slim lower profile computers / cases. It does come with features such as Active PFC, Dielectric Withstand, Remote ON/OFF and Smart Auto Fan Speed Controller. The exact model number of this Flex ATX PSU is AP-MFATX30P8.

Athena Power FlexATX 300W PSUSpecifications
Wattage 300W
12V Rail 28A (14A + 14A), Dual
Fan Size 40mm
80 Plus Certification Bronze
PCI-E Connector 6-Pin x 1
Warranty 3 year

Buy Athena Power FlexATX 300W PSU

FSP FSP220-60LE(80) PSU

Another Flex ATX PSU from FSP, but this one is of 220W capacity. However, it comes with enough current on its dual 12V Rails, which is 26A combined (16A + 10A). When it comes to connectors, then it has got basic connectors that you would generally require, which includes 20+4pin, CPU 12V (4-pin), Molex and SATA connector. It is an 80 Plus White certified power supply having typical efficiency of 72% at full load.

FSP-FSP220-60LE80-PSU

The cooling on this PSU is provided by a 40mm that is installed at the front, and blows air to the internal components of PSU, which is then expelled out from the rear. As always, this is a quality product from FSP, and comes with features such as Active PFC, OVP, OCP, SCP Protection.

FSP FSP220-60LE(80) PSU Specifications
Wattage 220W
12V Rail 26A (16A + 10A), Dual
Fan Size 40mm
80 Plus Certification White
PCI-E Connector NA
Warranty 2 year

Buy FSP FSP220-60LE(80) PSU

Seasonic SS-250SU Flex ATX PSU

A relatively affordable Flex ATX PSU from Seasonic, rated for 250 Watts capacity. The power supply comes with dual 12V rails having total combined current of 22S, and is 80 Plus Bronze certified. At the rear, there is a double ball bearing 40mm exhaust fan for removing heat generated inside due to internal components. It does not come with PCIe connector, but other connectors, such as SATA, molex are included.

Seasonic-SS-250SU-Flex-ATX-PSU

It is an ATX v1.0 compliant power supply, which means it comes with 20-pin motherboard connector. The PSU comes with Active PFC and protection & safety features that include Short circuit protection, Over voltage protection, Over power protection, 100 % HiPot test, 100 % Burn-in.

Seasonic SS-250SU Flex ATX PSU Specifications
Wattage 250W
12V Rail 22A (8A + 14A), Dual
Fan Size 40mm
80 Plus Certification Bronze
PCI-E Connector NA
Warranty Check with manufacturer

Buy Seasonic SS-250SU Flex ATX PSU

Some Budget Flex ATX PSUs

Here are some cheaper Flex ATX power supplies that you can check out:

Best Flex ATX PSU 500W

Here are some of the powerful Flex ATX 500W PSUs that you can get for your higher workload requirements.

FSP FSP500-50FSPT Flex ATX PSU

Here we have industrial grade 500W Flex ATX PSU from FSP, having model number as FSP500-50FSPT. The power supply comes with dual 12V Rails with combined current of 48A (24A + 24), but it is stated by manufacturer that the combined load on 12V Rail should not exceed 40A. Being such as powerful PSU, it does lack PCIe power connectors, which is a slight downside of this PSU. However, it comes with all other required connectors that include 24-pin ATX, 8-pin CPU, SATA and Molex. The cooling on this PSU is done by a 40mm fan at rear that works as exhaust fan.

FSP-FSP500-50FSPT-Flex-ATX-PSU

This is an 80 Plus Platinum certified PSU, which means it has efficiency of 95% at 50% load, and 90% efficiency at full load. It comes with Active PFC, and protection & safety features that include overvoltage protection, short circuit protection and others. It also features 100% burn-in under high ambient temperature(50°C) and is 100% Hi-pot tested. This small form factor FLEX ATX PSU is best suited for servers, workstations and slim small form factor computers.

FSP FSP500-50FSPT Flex ATX PSU Specifications
Wattage 500W
12V Rail 48A (24A + 24A), Dual
Fan Size 40mm
80 Plus Certification Platinum
PCI-E Connector NA
Warranty 3 year

Buy FSP FSP500-50FSPT Flex ATX PSU

Athena Power FlexATX 500W PSU

[SLI & Cross Fire ready]

A powerful 500W Flex ATX PSU for heavy duty applications including industrial. It is dual 12V Rail power supply that has combined current of 40A (20A + 20A) on it. It comes with all the required connectors, including two 8-pin (6+2) PCIe connectors that can be used to power a high-end graphics card. It is also a SLI & Cross Fire ready PSU, which is very rare in this compact form factor. The power supply is 80 Plus Silver certified, which has efficiency in between 80 Plus Bronze and Gold certifications.

Athena-Power-FlexATX-500W-PSU

The PSU is cooled down a 40mm fan that is situated at the rear, and works as an exhaust fan for taking the heat out. It comes with features such as Active PFC (Power Factor Correction), Thermal fan speed controller, 100% Hi-pot, ATE and Burn-in tested, Remote On/OFF function and protection features that include over voltage, short circuit and overload protection. So, if you are looking for a high capacity Flex ATX PSU for high-performance compact systems or servers, then it will serve your purpose very well.

Athena Power FlexATX 500W PSU Specifications
Wattage 500W
12V Rail 40A (20A + 20A), Dual
Fan Size 40mm
80 Plus Certification Silver
PCI-E Connector 8pin (6+2) x 2
Warranty 3 year

Buy Athena Power FlexATX 500W PSU

Fanless Flex ATX PSU

FSP Fanless Flex ATX 120W PSU

If you are looking for a Fanless Flex ATX PSU, then FSP120-50GNF is the one. It is a pretty basic 120W power supply that comes with single 12V Rail with 8A current on it. It comes with 20-pin ATX connector and eight 4-pin molex connectors for power. This PSU is completely silent in operation, because it does not come with fan, and is passively cooled. However, it does not compromise on safety, protection & efficiency and comes with features such Active PFC, OVP, OCP. It is only suitable for compact systems with much lower power consumption.

FSP-Fanless-Flex-ATX-120W-PSURelated: Best Fanless PSUs for Building a Silent PC

FSP Fanless Flex ATX 120W PSU Specifications
Wattage 120W
12V Rail 8A, Single
Fan Size 40mm
80 Plus Certification NA
PCI-E Connector NA
Warranty Check*

Buy FSP Fanless Flex ATX 120W PSU

See also: Best Budget PSU for Gaming PC

Final Words

At the end, I would like to say that good and reliable Flex ATX PSUs are relatively harder to find, because their availability and there are not much options to choose from. However, I have carefully selected and listed the best Flex ATX power supplies that you can get for your Mini-ITX Case, SFF PC or 1U Servers and for use in industrial applications. If you have got any questions or doubts regarding them, or their compatibility, then you can ask me your queries by leaving a comment below.
