There has been a tremendous improvement in PC Cases in recent years. Gone are the days when PC Cases were only meant to accommodate your computer components and did not offer anything extra. Now, PC Cases have become stylish & beautiful, modular, feature-rich, provide better airflow performance (for airflow-optimized cases), and offer additional functionality according to the user’s needs. From fancy RGB lighting, tempered glass panels, and modular design, the advancements in PC Cases have been quite substantial.
Nowadays, you can even find digital displays or LCD screens in some PC Cases that show you critical parameters like temperature, fan speed, clock speed, etc., for your CPU and GPU in real-time. Not only does the digital display or LCD screen look spectacular and futuristic, but it can also come in handy as you can monitor the CPU and GPU critical parameters, such as temperature, fan speed, etc., from outside without launching any monitoring software. For example, when gaming, you can easily monitor the CPU and GPU temperature if you suspect your CPU or GPU is overheating and can take necessary measures accordingly. Right now, there are only quite a few PC Cases with digital displays or LCD screens, but there are aftermarket LCD Screens available that you can attach or place anywhere inside your PC Case and view through the tempered glass side panels of your PC Case.
Best PC Cases with Digital Display or LCD Screen
Below are some good PC Cases with a Digital Display or LCD Screen.
JONSBO D41 MESH SCREEN Black ATX Computer Case
[8-inch fully functional LCD Screen, Compact yet Spacious, Decent Airflow]
JONSBO D41 MESH SCREEN is one of the best PC cases, and it comes with a full-fledged LCD screen offering full functionality and capability. JONSBO is a Chinese company and is quite a well-known brand in Asia for its good quality computer products. It is one of the biggest manufacturers of PC Cases in Asia, and it also manufactures PC Cooling products and PC Case accessories that include CPU Air Cooler, AIO Cooler, Case Fans, GPU Support Bracket/Stand, RGB LED RAM modules, RGB LED Strip, etc. JONSBO D41 MESH SCREEN Black is a mid-tower PC Case but is relatively compact compared to a standard mid-tower PC Case. The PC Case comes with a full-fledged 8-inch TFT LCD Screen at the front with a resolution of 1280 x 800 pixels and 16.7 million colors. The screen has a refresh rate of 60Hz, 30ms response time, 300cd/m2 brightness, contrast ratio of 1000, and operating temperature of 0 to 50 degrees Celsius. The screen uses a mini-HDMI connector for video signal and a USB Type-C connector for power and software connectivity. The LCD screen can also be used as a secondary display, or you can use it to display custom live wallpapers or important parameters in real-time associated with your CPU, GPU, etc., via AIDA64 hardware monitoring software (need to be purchased separately). The display screen is detachable and can be used with the PC Case or externally.
The Case supports up to ATX motherboards. Regarding cooling, the PC Case has sufficient fan mounting points at the front, rear, top, and bottom. The front and top panels have mesh construction for better airflow. The Case can fit a 168mm tall CPU Cooler, 400mm long graphics card, 360mm radiator, and a 220mm PSU. Front I/O ports include one USB 3.2 Gen 2 Type-C port, a USB 3.0 port, and Audio ports. The Case has a 1.1mm thick tempered glass panel with 6H thickness. For PSU mounting, the Case offers up to four levels of height adjustments for proper space management. The Case has three 2.5-inch drive bays for SSD storage and two 3.5-inch bays for hard drives. Other features include removable magnetic dust filters, optimized back cable routing, and rubber feet/stands. Aesthetic-wise, it is a stylish and modern-looking PC Case that stands out.
JONSBO D41 MESH SCREEN Black Case Specifications | |
Form Factor | Mid-Tower |
Motherboard support | ATX / Micro-ATX / mini ATX |
Drive Bays | 2.5″SSD x 3 + 3.5″ HDD x 2 |
Front I/O Ports | USB 3.2 Gen 2 Type-C x 1, USB 3.0 x 1, Audio & Mic |
Expansion Slots | 7 |
CPU Cooler Height | 168mm |
Graphics Card Length | 330-400mm |
PSU Compatibility | ATX/SFX up to 220mm Length |
Case Fans Support | Top: 120mm x 3 or 140mm x 2
Rear: 120mm x 1 Bottom: 120mm x 3 or 140mm x 2 Front: 120mm x 1 |
Radiator Support | Top: 240/280/360 x 1
Rear: 120 Bottom: 240/360 x 1 |
Digital Display / LCD Screen | 8-inch Color TFT LCD with 16.7M Colors and 1280 x 800 pixels Resolution, Screen |
Other Features | Mesh Front Panel, 1.1mm thick/6H Mohs Tempered Side Glass Panel, Removable Air/Dust Filters, Tool-free Installation, 4-levels PSU Height Adjustment, Optimized back cable routing |
Buy JONSBO D41 MESH SCREEN Black PC Case
DeepCool CH560 Digital Mid Tower PC Case
[Good Airflow, Spacious, Stunning Looks, ARGB LED Lighting, Dual-Status Digital Display]
DeepCool CH560 Digital is one of the best PC Cases you can get with a digital display on the side panel. It is a mid-tower high-airflow PC Case that also comes with a good number of features. The Case can fit up to an E-ATX size motherboard and is quite spacious. The digital display is fitted on the side of the PSU shroud and can be viewed through the hybrid side panel. It is a dual-status digital display that can display real-time information about the CPU and GPU temperatures and usage. The display uses an internal USB 2.0 connector for connectivity and DeepCool proprietary application/software for displaying the CPU/GPU parameters in real-time.
The hybrid side panel comprises a tempered glass panel at the top and a mesh panel at the bottom to optimize airflow. The mesh panel has a cut-out where the digital display can be seen from the outside. Regarding cooling and airflow, the Case offers ample fan mounting points at the front, top, and PSU shroud sides. Three 140mm ARGB fans at the front and one 120mm ARGB fan at the rear come pre-installed with the Case. The front and top panels have mesh construction, and the top panel uses a magnetic dust filter. I/O ports are located at the top and consist of a USB 3.0 Type-A port, Type-C port, LED button, and Audio ports. For storage, the Case supports two 3.5-inch drives and three 2.5-inch drives.
The DeepCool CH560 Digital PC Case can support up to 178mm tall CPU Coolers, 380mm long graphics cards, 360mm Radiator for AIO, and 170mm long ATX PSU. The Case also has an Integrated GPU Support Arm for eliminating gPU sag for long, heavy, high-end graphics cards. Regarding aesthetics, this PC Case is undoubtedly very stylish, modern, and beautiful. Overall, it is a very well-made, beautiful PC Case with a Digital Display and is also quite affordable.
DeepCool CH560 Digital PC Case Specifications | |
Form Factor | Mid-Tower |
Motherboard support | Mini-ITX / Micro-ATX / ATX / E-ATX |
Drive Bays | 3.5” x 2, 2.5” x (2+1) |
Front I/O Ports | USB 3.0 x 1, USB 3.0 Type-C x 1, Audio, LED button |
Expansion Slots | 7 |
CPU Cooler Height | 175mm |
Graphics Card Length | 380mm |
PSU Compatibility | ATX PS2 up to 170mm |
Case Fans Support | Front: 3 x 120 / 3 x 140mm Top: 3 x 120 / 2 x 140mm Rear: 1 x 120 / 1 x 140mm PSU Shroud: 2 x 120mm |
Radiator Support | Front: 120/140/240/280/360mm Top: 120/140/240/280/360mm Rear: 120/140mm |
Digital Display / LCD Screen | Dual-status Digital Display on Side Panel |
Other Features | Mesh Front Panel and Top Panel, Hybrid Side Panel with Tempered Glass and Mesh, Magnetic Air Filters, Integrated GPU Support Arm, 26mm of cable management at the back, |
Buy DeepCool CH560 Digital Mid Tower PC Case
Antec Performance 1 FT Full Tower Case
[Good Airflow, Feature Rich, Spacious, Feature Rich, Modular Design]
If you are looking for a high-quality, high-performance, and feature-rich big PC Case with a Digital Display, then Antec Performance 1 FT is what you need. It is a high-airflow full-tower computer case that supports E-ATX motherboards. It has a digital display at the top of the front panel that shows the CPU/GPU temperature, which can be turned ON or OFF using the temperature display button on the Case’s top panel. The digital display is configured using the Antec iUnity software, a hardware monitoring and tweaking proprietary software from Antec. The PC Case has good ventilation and airflow and has up to 10 fan mounting points. It comes pre-installed with three Storm T3 PWM 140mm fans at the front and one 120mm at the rear. The Case comes with modular drives for storage and supports up to 5 drives: 2 removable drive trays for 3.5″ HDD/2.5″ SSD & 3 drive trays for 2.5″ SSD.
The Case can support up to 175mm tall CPU Coolers, 400mm long graphics cards, 440mm PSU (w/o HDD), and 420mm Radiator on the Front. It can also accommodate two 360mm Radiators simultaneously, one on the front and one at the top. The build quality of the PC Case is outstanding, and it weighs 15 Kg. The Case comes with 4mm thick tempered glass panels on both sides, i.e., left and right. The top panel has a magnetic air filter, and the top cooling is detachable for easy access. Other features of the Antec Performance 1 FT PC Case include a Back-mounted PSU Bracket, Cable Management, Rubber Grommets and Velcro Straps for Cable Routing, Magnetic Dust Filters, Drop-proof bolts, etc. Regarding design and aesthetics, the Case looks futuristic and strikingly beautiful. Overall, it is an excellent PC Case with a digital display that is also quite affordable. Highly Recommended!
Note: Antec Performance 1 FT Full Tower Case is also available in White Color, and an ARGB model of this Case is also there that comes with ARGB Fans pre-installed. You can check both these models from the link below.
Antec Performance 1 FT Full Tower Case Specifications | |
Form Factor | Full Tower |
Motherboard support | E-ATX, ATX, Micro-ATX, ITX |
Drive Bays | 3.5” / 2.5” x 2 / 2, 2.5” x 3 |
Front I/O Ports | USB 3.0 x 2, Type-C 10Gbps x 1, Audio, Temperature Display Button |
Expansion Slots | 8 |
CPU Cooler Height | 175mm |
Graphics Card Length | 400mm |
PSU Compatibility | 245mm (with HDD) / 440mm (without HDD) |
Case Fans Support | Front: 120mm x 3 / 140mm x 3
Top: 120mm x 3 / 140mm x 3 PSU Shroud: 120mm x 3 Rear: 120mm x 1 |
Radiator Support | Front: up to 420mm
Top: up to 360mm Rear: 120mm |
Digital Display / LCD Screen | Digital Temperature Display on Top Panel |
Other Features | Magnetic Dust Filters (Top/Front/Bottom), 4mm Tempered Glass Side Panels (Left & Right), Rubber Grommets for Cable Routing, Rear Velcro Straps, Mesh Front Panel, Mesh at Bottom, Pre-installed Storm T3 PWM Fans (30mm thick), Removable Top Cooling Bracket, Dust Plugs for I/O Panel Female Ports, Back-mounted PSU Bracket. |
Buy Antec Performance 1 FT Full Tower Case
GAMDIAS ATLAS M1 Mid Tower Gaming Computer Case
[Stunning Looks, Good Digital Display, Vertical GPU Mounting Support, Relatively Compact but Spacious, ARGB LED Lighting, Budget Friendly]
GAMDIAS is a Taiwan-based company that manufactures gaming peripherals and components. It has a global reach and is a well-known gaming brand, mainly because of its high-quality computer cases. Here we have GAMDIAS ATLAS M1, a Mid Tower Gaming Computer Case with a digital display located on its side. The Case supports up to ATX motherboards and has ample space for your high-end gaming components, including flagship graphics cards and big AIOs. It is a stylish-looking Case with tempered glass panels at the front and side. For cooling, the Case offers six fan mounting points and comes pre-installed with two 120mm ARGB PWM fans at the side and one at the rear. The front 120mm side fans are reverse intake fans that allow intake of fresh air in the Case. The digital display on the side shows CPU, GPU, and ambient temperature and uses the ZEUS CAST software. Users can also switch between CPU/GPU/AMB/OFF modes through the Temp button on the I/O port. Front I/O ports are located along the side of the digital display, consisting of a USB 3.0 port, Type-C port, Audio ports, Temp button, and LED control button.
The Case can support 160mm tall CPU Coolers, 410mm long high-end graphics cards, PSU up to 180mm long, and 360mm Radiators for AIO. GAMDIAS ATLAS M1 PC Case can also support vertical mounting of graphics cards as it has two vertical expansion slots at the back. The build quality of the Case is very good, and it is also very competitively priced. Other features include magnetic dust filters, PSU Chamber Vents, and Cable Management. Overall, it is a stunning-looking case that offers a great inside view of components for users to admire. This Case is quite budget-friendly and also comes in White color.
GAMDIAS ATLAS M1 Gaming Computer Case Specifications | |
Form Factor | Mid Tower |
Motherboard support | ATX, Micro-ATX, Mini-ATX |
Drive Bays | 3.5” x 1, 2.5” x 2 |
Front I/O Ports | USB 3.0 x 1, Type C x 1, HD Audio x1, LED Control x1, Monitor Mode Switch x 1 |
Expansion Slots | 7+2 |
CPU Cooler Height | 160mm |
Graphics Card Length | 410mm |
PSU Compatibility | ATX up to 180mm |
Case Fans Support | Top: 120mm x 3 / 140mm x 2
Side: 120mm x 2 Rear: 120mm x 1 |
Radiator Support | Top: 360mm/280mm
Side: 240mm Rear: 120mm |
Digital Display / LCD Screen | Digital Display on Side (CPU/GPU/Amb Temperature Display) |
Other Features | Magnetic Dust Filters (Top, Bottom), Tempered Glass Panels (Front/Side), Vertical GPU Mounting Support, PSU Chamber Vents, Cable Management |
GAMDIAS ATLAS M1 Mid Tower Gaming Case [Black]
GAMDIAS ATLAS M1 Mid Tower Gaming Case [White]
Third-Party/Aftermarket LCD Screens for PC Case
There are also aftermarket or third-party custom LCD screens available that you can install inside your Case on the tempered glass panel side to monitor CPU, GPU temperature, usage, fan speed, and even more. These LCD Screens are mostly Chinese and not from any reputed brand. Here are some LCD screens that you can check out.
- Wisecoco 12.6 Inch FHD LCD Panel IPS Second Screen
- Wisecoco 12.6 Inch Secondary Screen FHD IPS Touch Monitor
- WOWNOVA PC Temperature Display Computer Temp Monitor
Final Words
There is no denying that, besides aesthetics, a digital display or LCD Screen adds extra functionality to your PC Case and can prove very helpful in monitoring CPU/GPU temperature just by having a quick glance at it. These PC Cases are quite rare as of now, but we can expect to see more of them in the future. If you have any doubts or questions regarding Computer Cases with digital displays or LCD screens, please let me know in the comment section below.
