Best Slim 120mm Fan for SFF Cases, Heatsinks & Radiators in 2019

I have already covered best 120mm case fans in this blog but here I am going to cover best slim 120mm fans that are thinner than the normal 120mm fans. A regular or standard 120mm fan is 25mm thick but a slim 120mm fan is only 15mm thick which is considerably thinner. Slim 120mm fan is also known as thin 120mm fan, low profile 120mm fan or 15mm thin 120mm fan.

These slim case fans can be used in low profile CPU coolers / heatsinks, low profile cases and small form factor (SFF) cases where there is no or very little room for a regular sized fan. They can also be used on radiators (120mm / 240mm / 360mm radiators) and normal PC cases to free up some space for other components in a congested environment. You may also use them on passive GPU coolers if you want better cooling from on passively cooled graphics card. In PC case they can be used as front fans, rear fans and top mounted fans. These slim 120mm fans might offer a bit less airflow compared to the standard 120mm fans because of their thinner fan blades. However, the difference is marginal and they can offer almost the same performance of a standard 120mm fan and that too with consuming less space. So, lets get started with the best 120mm slim fans for use in PC cases, CPU coolers and Radiators.

Check out:

Top Slim 120mm Fans [15mm Thin Low Profile Fans]

Here are the best low profile 120mm fans that you can use with small PC cases, standard computer cases, low profile heatsinks / coolers and radiators. All these below mentioned slim 120mm fans have thickness of 15mm only.

Noctua NF-A12x15 PWM Slim 120mm Fan

Noctua NF-A12x15 PWM is a quiet and slim 120mm fan for use in low profile CPU coolers, SFF HTPC PC cases and 120mm / 240mm / 360mm radiators for liquid CPU coolers. This thin 120mm fan is also present in the Noctua NH-L12S Low Profile CPU Cooler. The fan comes with Noctua’s SSO2 bearing for quiet operation and longer lifespan. This is a PWM fan and is very silent in operation and comes with low noise adapter (L.N.A.).

Noctua-NF-A12x15-PWM-Low-Profile-Fan

It has speed in the range of 450 – 1850 RPM and airflow of 55.4 CFM which is very good for a slim fan. To reduce vibrations, the fan has got rubber padding on all the corners. This slim 120mm fan has great build quality along with commendable performance. It is also very stable and is backed 6-year warranty from Noctua. It is one of the best slim fans for use in low profile CPU coolers and you can also use it as an extra fan in standard CPU coolers in push and pull configuration.

Noctua NF-A12x15 PWM Low Profile Fan Specifications
Fan Size 120mm
Bearing Type SSO2
Fan Speed 450 – 1850 RPM (1400 RPM with L.N.A.)
Connector Type 4-pin PWM
Maximum Airflow 55.4 CFM
Noise Level 23.9 dBA

Buy Noctua NF-A12x15 PWM Slim 120mm Fan

Noctua NF-A12x15 FLX Slim 120mm Fan

This is the 3-pin connector variant of the above mentioned Noctua NF-A12x15 PWM fan. Noctua NF-A12x15 FLX has got the same specifications, quality and design as of Noctua NF-A12x15 PWM fan but the only exception is that its speed cannot be varied because of the 3-pin connector. However, it comes bundled with Low noise adapter (L.N.A.) and Ultra noise adapter (U.L.N.A.) cables that can allow to you to adjust speeds at 1400 RPM and 950 RPM respectively.

Noctua-NF-A12x15-FLX-Slim-120mm-Fan

It has got maximum speed of 1850 RPM and comes with 3:4-pin power supply adapter for connecting directly to the 4-pin Molex connector of the PSU.  It may not be suitable for low profile CPU coolers because of 3-pin connector but is great for use in PC cases and Radiators.

Noctua NF-A12x15 FLX Low Profile Fan Specifications
Fan Size 120mm
Bearing Type SSO2
Fan Speed 450 – 1850 RPM (1400 RPM with L.N.A. / 950 RPM with U.L.N.A.)
Connector Type 3-pin
Maximum Airflow 55.4 CFM
Noise Level 23.9 dBA

Buy Noctua NF-A12x15 FLX Slim 120mm Fan

Prolimatech Ultra Sleek Vortex 12 Fan

A very silent and high quality sleek 120mm fan from Prolimatech that is only 15mm thick. This is a PWM fan and comes with 17 blades that are designed for providing high airflow and static pressure. The fan comes with double ball bearing and rotates at speed in range of 400 to 1300 RPM. It generates high airflow of 56 CFM and static pressure of 0.9mmH2O, and is the quietest slim 120mm fan with maximum noise level rating of 17 dBA only.

Prolimatech-Ultra-Sleek-Vortex-12-Fan

The build quality of the fan is superb and it is very lightweight. You can use this fan on low profile CPU coolers or as an extra fan on standard CPU air coolers in push-pull configuration, and can also use this as a case fan or cooling fan on radiators. A 4-pin PWM to molex connector cable comes bundled with this slim fan. So, if you are looking for a premium high performance slim 120mm fan for your various cooling needs then you will not be disappointed at all.

Prolimatech Ultra Sleek Vortex 12 Specifications
Fan Size 120mm
Bearing Type Double Ball Bearing
Fan Speed 400 – 1300 RPM
Connector Type 4-pin PWM
Maximum Airflow 56 CFM
Noise Level 17 dBA

Buy Prolimatech Ultra Sleek Vortex 12 Fan

Cooler Master XtraFlo 120 Slim Fan

A slim 120mm PWM fan from Cooler Master. This is a high performance low profile fan with maximum airflow of 57.4 CFM. The speed of the fan ranges from 500 to 1600 RPM. It has got unique wave shaped fan blades for high airflow and static pressure. However, the fan is a bit on the louder side at maximum speed. It comes with Anti-vibration rubber pads around the edges to decrease noise and vibrations. Because it is a PWM fan which means it can also be used on low profile heatsinks for CPUs but it is best suited as a case fan only because of its design.

Cooler-Master-XtraFlo-120-Slim-Fan

Cooler Master XtraFlo 120 Slim Fan Specifications
Fan Size 120mm
Bearing Type Long Life Sleeve
Fan Speed 500 – 1600 RPM
Connector Type PWM
Maximum Airflow 58.4 CFM
Noise Level 30 dBA

Buy Cooler Master XtraFlo 120 Slim Fan

Thermaltake Luna 12 Slim LED Fan

Here we have a Slim 120mm Fan from Thermaltake with LED light. Thermaltake Luna 12 Slim LED Fan comes with hydraulic bearing for longer life and silent operation. The fan has got 3-pin connector and has constant speed of 1400 RPM. The fan is silent in operation but has relatively less performance as it does not move that much amount of air compared to the competition. The airflow is only 27.5 CFM which is definitely on the lower side of the spectrum for a 120mm fan.

Thermaltake-Luna-12-Slim-LED-Blue

The build quality of the fan is very good and it comes with ant-vibration pads on all four corners for reducing noise and vibrations. It has got nine transparent fan blades that looks great in the presence of LED lighting. The fan is available in three colors (red/white/blue) depending on your choice. So, if you are looking for a Slim LED fan then go for this but if you are purely looking for performance then get other fan especially the Noctua one.

Thermaltake Luna 12 Slim LED Fan Specifications
Fan Size 120mm
Bearing Type Hydraulic Bearing
Fan Speed 1400 RPM
Connector Type 3-pin
Maximum Airflow 27.533 CFM
Noise Level 24 dBA

Buy Thermaltake Luna 12 Slim LED Fan

Scythe Slip Stream 120mm Slim Case Fan

If you are looking for a cheap 120mm slim fan then this is the fan that you can get for your needs. This is just a basic slim 120mm fan that comes with cheap sleeve bearing and has constant fan speed of 1600 RPM. The fan comes with 3-pin connector and it also includes a 3-pin to 4-pin molex adapter. The fan is on the noisier side and generates airflow of 38.05 CFM which is quite decent. This fan must only be used as case fan and should be avoided on CPU coolers and Radiators because of its cheaper build and mediocre performance. It is also available in 800 RPM, 1200 RPM and 2000 RPM speed variants. Great budget slim 120mm fan for users on tight budget.

Scythe-Slip-Stream-120-mm-Slim-Case-Fan

Scythe Slip Stream 120mm Slim Case Fan Specifications
Fan Size 120mm
Bearing Type Sleeve Bearing
Fan Speed 1600 RPM
Connector Type 3-pin
Maximum Airflow 38.05 CFM
Noise Level 28.89 dBA

Buy Scythe Slip Stream 120mm Slim Case Fan (1600 RPM)

Buy Scythe Slip Stream 120mm Slim Case Fan (2000 RPM)

Rosewill RASF-141213 – 120mm Ultra Slim Fan

A budget 120mm Slim Fan from Rosewill that comes with a PWM connector. This fan very much resembles the design of the above mentioned Cooler Master XtraFlo 120 Slim Fan with similar wave shaped fan blades and overall design. The speed of the fan ranges from 600 to 1600 RPM and it comes with Sleeve bearing. The fan moves decent amount of air @54.55 CFM but is a bit noisy and has maximum noise level rating of 30.32 dBA.

Rosewill-RASF-141213-–-120mm-Ultra-Slim-Fan

The build quality of fan is pretty good and it great for use as a case in ultra slim computer cases. It is best suited for use as an exhaust fan but can be used as a front intake fan too. Overall, it is a good low profile 120mm fan that is cheap and delivers good performance for the price.

Rosewill RASF-141213 – 120mm Ultra Slim Fan Specifications
Fan Size 120mm
Bearing Type Long Life Sleeve
Fan Speed 600 – 1600 RPM
Connector Type 4-Pin
Maximum Airflow 54.55 CFM
Noise Level 30.32 dBA

Buy Rosewill 120mm Ultra Slim Fan

Phobya G-Silent 12 Slim Edition Fan

An attractive looking slim 120mm fan that has got black frame and red fan blades. The fan is from a German company called Aquatuning, which specializes in PC cooling and modding hardware. It is a very good budget slim fan that offers great performance at lower price. The fan comes with Hydrodynamic bearing and has spins at speed of 1800 RPM.

Phobya-G-Silent-12-Slim-Edition-Fan

The fan generates high airflow of 58 CFM and is pretty quiet in operation. The maximum noise level rating for this fan is 28.5 dBA which is quite okay and it can pass as a silent fan. The fan uses 3-pin connector and has got sleeved cable for extra protection. Due to high airflow and 3-pin connector, the fan is best suited for use as a case fan, both as exhaust and intake. The fan is well built and sturdy, and also has provision to integrate 3mm LEDs if you want a bit of fancy stuff going on.

Phobya G-Silent 12 Slim Edition Fan Specifications
Fan Size 120mm
Bearing Type Hydrodynamic bearing
Fan Speed 1800 RPM
Connector Type 3-pin
Maximum Airflow 58 CFM
Noise Level 28.5 dBA

Buy Phobya G-Silent 12 Slim Edition Fan

SilverStone FN123 Slim 120mm Fan

SilverStone FN123 is budget slim 120mm fan that combines the qualities of both airflow and static pressure fan. The fan has longer curved blades and they have very small distance between them. This makes it a good high static pressure fan for use in Radiators, CPU coolers and as a front intake fan. It has static pressure rating of 1.52mmH2O which is quite good.  The fan blades are very stable because they are joined to each other along the middle part.

SilverStone-FN123-Slim-120mm-Fan

The build quality of this 120mm slim fan is average but is not bad either. The fan uses 3-pin connector and has maximum speed of 2000 RPM. It can be a bit loud because of its higher RPM. The fan is very much affordable and is great budget slim fan for slim PC cases.

SilverStone FN123 Slim 120mm Fan Specifications
Fan Size 120mm
Bearing Type Long life sleeve
Fan Speed 2000 RPM
Connector Type 3-Pin
Maximum Airflow 32.6 CFM
Noise Level 23.5 dBA

Buy SilverStone FN123 Slim 120mm Fan

Deepcool GS120 Slim Fan

[20mm Thick & Highest Airflow]

Deepcool GS120 Gamer Storm is a 120mm slim case fan having thickness of 20mm, which is a bit more than a regular 15mm slim fan but lesser than a standard 25mm fan. The fan allows you clear out 5mm of space for other components, and that too without compromising any cooling performance. This a PWM fan with speed in range of 900 – 1800 RPM, and it comes with Hydro Dynamic bearing for longer lifespan.


The fan generates high airflow of 62 CFM but is rather noisy at full speed (32.4 dBA Noise rating). However, you can reduce the noise by using the 7 Volt Low-noise adapter that comes bundled with the fan. Also comes included with the fan are 4 rubber screws for installation and 2 rubber cable ties for cable management. It can be used as a case fan (both as exhaust and intake), and on standard or low profile CPU coolers. Also, it can be used as a replacement fan in power supplies with 120mm fan. The fan looks very elegant with white fan blades & grey frame, and has good build quality too. It is also quite cheap and gets a thumbs up from me.

Deepcool GS120 Slim Fan Specifications
Fan Size 120mm [20mm Thick]
Bearing Type Hydro Bearing
Fan Speed 900 – 1800 RPM
Connector Type 4-pin PWM
Maximum Airflow 61.93 CFM
Noise Level 32.4 dBA

Buy Deepcool GS120 Slim Fan

See also:

Final Words

These slim 120mm fans are really a lifesaver when it comes to tight spaces in your PC case or you have very low clearance for other components. Some of these thin 120mm fans can also be used as an extra fan for your CPU cooler, but most of times they are used as case fans and with thick radiators. If you have any doubts or queries regarding them then please ask me by leaving a comment below.
